pethier

Is the storm cap or rain cap? My storm cap for the SLR cage fits around the boot cover

The ring and pinion I have in 74PHIL is 4.11/1 and works just fine for autocrossing with the T9 5-speed with its drop 1st. There is some sort of plated LSD in there which seems OK. The ring and pinion I have in the CSR 260 is 3.62/1. The transmission is the Caterham all-close-ratio 6-speed. Together, they give what roadracers call a "Useable First". This is what autocrossers call an "UNuseable First". I'm having a Sierra diff made up with a ring and pinion of 4.71/1 and a Drexler LSD. The overall launch ratio will still be lazier than 74PHIL. I'll keep my 3.62/1 Quaife ATB differential lying around in case my heirs want to sell the car to a big-track fan.

Thanks!

Yeah, I missed it. But no way was it the ratio I wanted.

Excellent. I assume the wheels have steel inserts with conical seats. Much-better design than original Brand Lotus wheels.

LOL

I think I recently referred to this as a "stub axle" because I just could not remember the word "spindle". Thanks for reminding me.

Brand Lotus wheels? Folks often have balance issues with these wheels. I have found it is often a problem with the lug nuts. The outside diameter of the nut is often not concentric with the internal thread.

Same thing.

Looks like yours has a RaceLine water rail like mine does.

It looks like the stem/ball part may be the same. I have not measured the ball. The stem end is interchangeable: 5mm thread. The other pieces are not the same. The bolt pattern of the foot is the same, both fit the two small holes on the cage. The big nut on the outside or the setscrew from the back are different and require a different foot design. There is no indication of how the Lifeline mirrors actually mount. My Flickr album shows the hardware to mount the SPA or other mirrors having a 5mm female thread on the arm mount to a flat surface with 2 mounting holes that are about 38mm apart, center to center. The WESTMO does not need the big hole between the two small ones. If you are going to bolt this type of foot on an aeroscreen instead of something flat, see https://uberniche.co.uk/spa-mirror-shims

My old friend Slide Hammer. Yes, the theory is to use a machine screw. The screw presses against the end of the stub axle and presses the cap off. The practice is that the hole in the cap is messed up and the cap has mated itself in place. If the original threads are not up to the task, put a sheet-metal screw into your slide hammer and use it to suggest the cap move out. Keep hitting it harder until it decides to move. Some caps have a male stud instead of a hole. They are not even pretending that the press will work, and expect a slide hammer.

Nice to know. Lifeline give a choice of two shapes, but only show the picture of one shape. In my case, I already had two mirrors, it was just that the mount for one mirror was cracked and unusable. I bought two compatible mounts of a different design which seems to be more convenient and and more durable.

When I got my CSR 260, the left mirror was unusable because the mounting at the roll cage was loose. The adjustment was to be tightened by using an Allen key from the back side of the mount through a hole in the mounting plate. This was going to be futile because the mount was cracked from overtightening. This design seemed flawed to me. While investigating WESTMO in Germany, I found they had a better way: A solid mount with no hole on the back side. The ball was to be captured by a large nut that could be tightened from the outside. These shots are in an album at Flickr, some with extra captions I am not going to try to organize here: https://www.flickr.com/photos/pethier/albums/72177720335280753/

I think the Birkin I have was made as a 2003 model. It does not have this tag in this location.
